RISON TITANIUM Extended Series – M8x1.25x65mm Titanium Stud Kit (12-Piece Set)
Upgrade your engine hardware with the ultimate heavy-duty clamping solution. This 12-piece premium titanium stud kit includes matching nuts and washers, precision-engineered from GR5 (Ti-6Al-4V) Aerospace-Grade Titanium.
At 65mm extended length, this kit is specifically designed to solve thread-engagement issues on heavily modified engines. If you are running ultra-thick aftermarket intake manifolds, thick phenolic thermal isolation gaskets, or stacked plenum spacers, standard 45mm or 55mm studs simply won't reach. The 65mm version provides the extra thread depth needed to ensure a rock-solid, leak-free seal without stripping your aluminum cylinder head.
Specifications
Specification Value
Thread Size M8 × 1.25
Total Length 65mm
Material GR5 Titanium Alloy (Ti-6Al-4V / TC4)
Kit Contents 12 Extended Studs + 12 Hex Nuts + 12 Washers (36 Pcs Total)
Tensile Strength ≥900 MPa to 1050 MPa
Thread Type Fully Rolled Threads (Increased Fatigue Resistance)
Corrosion Resistance 100% Rustproof & Anti-Seize
Fitment & Compatibility – Honda / Acura & More
The universal M8x1.25 thread pitch is an industry-standard for import tuning, particularly on Honda and Acura platforms. This 65mm extra-long kit is confirmed to fit:
  • B-Series: B16A, B16B, B18C, B20B (Civic Si/EG/EK, Integra DC2)
  • D-Series: D15, D16 (Civic, CRX, del Sol)
  • F-Series: F20B, F20C, F22C (S2000 AP1/AP2, Accord)
  • H-Series: H22A, H23 (Prelude)
  • K-Series: K20, K24 (Intake side / manifold runners)
⚠️ CRITICAL FITMENT NOTE: Standard factory manifolds use 45mm studs. Modified setups with standard thermal gaskets use 55mm studs. This 65mm kit is strictly for extreme, ultra-thick applications—such as multi-layer spacer stacks, extra-thick intake plenums, or custom throttle body/manifold fabrications where the flange-to-gasket thickness exceeds normal aftermarket standards. Please measure your total flange thickness before ordering.
Why Professional Builders Choose GR5 Titanium
  • Zero Rust, No Seizing: Steel hardware in high-heat zones inevitably scales, rusts, and fuses over time. RISON Titanium is 100% corrosion-resistant. No more snapped bolts or painful extractions when removing your manifold.
  • Protects Aluminum Cylinder Heads: Titanium expands and contracts at a rate closer to modern aluminum heads than harsh steel does, preventing thread galling and minimizing the risk of destroying your head's soft internal threads.
  • Aerospace Strength: Featuring precision rolled threads (not cut threads), our studs deliver a tensile strength over 900 MPa. They won't stretch or deform under high vibrational stress or extreme boost pressures.
  • Weight Reduction: At 45% lighter than OEM steel hardware, this kit sheds unsprung weight from the absolute top of your engine block.
Premium Finish Options (12 Styles Available)
  • Titanium Raw: Cleaned and passivated natural silver metal finish. Clean, mechanical, and timeless.
  • Burnt Blue (Hand-Torched): Individually flame-anodized by hand. Features organic, rich gradients. Slight piece-to-piece variations showcase its true custom nature.
  • PVD Vacuum Coated (Gold / Black / Rainbow / PVD Burnt Blue): Utilizing high-tech physical vapor deposition for a mirror-smooth, ultra-hard, scratch-resistant surface with perfect color uniformity.
  • Anodized Series (Green / Purple / Candy / Blue Purple / Lake Blue): Electro-chemical anodization that delivers vivid, deep, and highly saturated engine bay accents.
Essential Installation Guide
  1. Never Install Dry: Titanium-on-aluminum or titanium-on-titanium contact can cause cold-welding (galling). Always apply a high-quality, nickel-based anti-seize to the threads entering the block. Do not use copper-based anti-seize (risks galvanic reaction).
  2. Prep the Block: Thoroughly chase the cylinder head threads with an M8x1.25 thread tap/chaser and flush clean with brake cleaner. Remove all old crust, oil, and debris.
  3. Hand Tighten First: Always thread the studs into the block by hand until finger-tight. Never use an impact gun to install or spin titanium fasteners.
  4. Torque to Spec: Use a calibrated torque wrench to tighten down to your factory or manifold manufacturer's torque specifications.
  5. Heat Cycle Check: Re-torque the nuts after your engine's first complete heat cycle, and re-verify torque again after the first 50–100 km of driving.
About RISON TITANIUM
  • Manufactured strictly under ISO9001:2015 & AS9100:2018 aerospace quality management standards.
  • Proud Member of the American Titanium Industry Association.
  • Massive global inventory with over 60,000 fasteners ready in stock. Fast dispatch within 1–2 business days.
  • Custom sizing, unique thread pitches, and bespoke colors are available upon request. Contact our engineering team today.
Package Includes: 12x GR5 Titanium Studs (M8x1.25x65mm), 12x GR5 Titanium 12-Point/Hex Nuts, 12x GR5 Titanium Washers.
Note: International buyers are responsible for any local customs clearance fees or import duties incurred.
